InfiniSolar WP 30 KW 3P

InfiniSolar WP

30 KW 3P

Rated Power

3P 30 KW 500-900 V

PV Array Power

40000 W

MPPT Range

350 - 900 VDC

IP65 Waterproof

& Dustproof

Feed-in To

The Grid

Dual AC Input For

Utility and Generator

Support Multiple

Parallel Up To 4

Touch Screen

Display

Max Charge

50 A

Categories: , Product ID: 24849

Description

Overview:
3-phase IP65 hybrid solar inverter supports 150% unbalance load , With Ingress protection to IP65, InfiniSolar WP 30kW is suitable for use both in outdoor applications and indoor environments where atmospheric moisture and dust are present. It supports 150% unbalance load and the maximum load is up to 15kw for each phase. This flexibility can facilitate various power consumption in a home environment. With built-In AC coupled function, the existing on-grid system can be easily upgraded and expanded to a hybrid system. InfiniSolar WP 30Kw also offers a second terminal for the users choice as a generator input or a programmable output.



Main Features:

  • 150% unbalanced load support
  • Dual outputs selected as either programmable output or generator input.
  • Buit-in AC coupled function.
  • Built-in WiFi for mobile monitoring (App is available)
  • User-adjustable charging current up to 80A
  • Wide battery input range
  • Built-in communication port for BMS (RS485)
  • 5 years warranty
  • Parallel operation up to 4 units
